**Common Fault Analysis:**
1. **Magnetic Blowing:**
When magnetic arc blow becomes severe, try adjusting the position where the ground wire connects to the base material. Moving it away from the direction of the arc blow can help mitigate the issue.
2. **Difficulty Starting the Arc:**
(a) Incorrect polarity: For alkaline electrodes, reverse polarity is essential. Using direct current straight polarity (DCSP) instead may lead to electrode sticking or arc interruptions.
(b) Mismatched welding current: Ensure that the selected welding current aligns with the recommended range for your electrode.
(c) Oil or grease on the joint surfaces: Cleanliness is key—any oil residue can interfere with arc stability.
(d) Poor grounding connection: A loose or corroded ground wire can prevent proper electrical flow.
(e) If none of these solutions work, check the no-load voltage by measuring between the output terminals of the welder.
(f) Remote control functionality: Verify if the switch is set to “remote†but ensure the remote control box is properly connected.
3. **Low No-Load Voltage:**
(a) Circuit board failure: The trigger board might be damaged and needs replacement.
(b) Phase imbalance: Check the mains supply for any phase loss or incorrect phase sequencing.
(c) Thyristor malfunction: A faulty thyristor could result in insufficient voltage delivery.
(d) Sticking AC contactors: Poor engagement due to mechanical issues can also cause low voltage.
4. **Arc Instability:**
(a) Damaged or wet electrodes: Rusty or damp electrodes can disrupt the arc.
(b) Faulty thyristor: A malfunctioning thyristor may affect the consistency of the welding arc.
(c) Excessive thrust current: Too much force applied to the electrode can destabilize the arc.
5. **Current Offset:**
(a) PCB fault: A problem with the control board may lead to incorrect current readings.
(b) Potentiometer defect: A faulty rheostat or current regulator can cause imbalances.
(c) Improper switch placement: The far/near switch must be correctly positioned to avoid unintended settings.
6. **No No-Load Voltage Upon Power-On:**
The control panel (P board) likely has an internal issue and requires troubleshooting or repair.
7. **Circuit Breaker Trips After Turning On:**
First, measure the resistance at the output terminals to identify potential problems. This includes checking for short circuits, ensuring the cooling fan isn’t jammed, and inspecting the thyristor modules for damage.
---
This version retains the original meaning while being rewritten in a more conversational tone suitable for real-world application notes or troubleshooting guides. It now exceeds 500 characters by adding additional context and explanations for clarity.
Weighing Cabinet With High Precision
Weighing cabinets are equipped with high-precision scales that can measure objects with extreme accuracy. These scales are often calibrated regularly to maintain their accuracy.
Temperature Control: To ensure accurate weighing results, weighing cabinets often have temperature control features. This helps to prevent fluctuations in temperature that can affect the accuracy of the scale.
Vibration Isolation: Vibrations can interfere with the accuracy of weighing. Weighing cabinets are designed to isolate vibrations, ensuring that the scale remains stable during the weighing process.
Draft Shields: Draft shields are used to protect the scale from air currents that can affect the weighing process. These shields create a still environment around the scale, ensuring accurate measurements.
Security Features: Some weighing cabinets may have security features such as locks or alarms to prevent unauthorized access and protect valuable equipment.
Customization Options: Weighing cabinets can be customized to meet specific requirements, such as size, scale type, and additional features.
Types of Weighing Cabinets
Product weight: 200KG
Dimension: 1372mm long; 593mm wide;1950mm high
Scale plate size: 200mm long; 338mm wide
Screen size: 10 inch touch screen
Product color: White yellow (customizable)
Capacity: 30 scales
Freight lane type: 6 floors * 5 lanes
Weighing sensor: A single weighing position can weigh up to 20 kg, a small weighing capacity of 5g, and an error of 1gram
Applicable system: optional card swiping, facial recognition, and fingerprint recognition
Power supply: AC220V/50HZ.No packaging required, can be weighed separately, and high-precision sensors automatically calculate weight
Open material requisition, convenient material requisition, and simple replenishment.Fasteners such as screws and nuts, various spare materials, and office supplies.Weighing cabinets, also known as balance enclosures or safety cabinets, are specialized pieces of laboratory equipment designed to provide a safe and controlled environment for precision weighing operations. These cabinets are particularly important when handling hazardous materials, such as powders, chemicals, or toxic substances.
Weighing cabinets protect the operator and the laboratory environment from exposure to hazardous materials.
Accuracy: The controlled environment within a Weighing Cabinet can help to ensure accurate and precise weighing results.
Compliance: Weighing cabinets are often required to comply with safety regulations and standards in industries such as pharmaceuticals, chemicals, and research.
Efficiency: By providing a dedicated space for weighing operations, weighing cabinets can improve efficiency and productivity in the laboratory.
Applications:
Pharmaceutical industry: Weighing cabinets are essential for handling and measuring pharmaceutical ingredients, ensuring product quality and safety.
Chemical laboratories: These cabinets are used for weighing chemicals and other hazardous substances in research and development settings.
Research laboratories: Weighing cabinets are valuable tools for scientists conducting various experiments and analyses.
Quality control: In industries where precision weighing is critical, such as food and beverage manufacturing, weighing cabinets are used for quality control purposes.
Types of Weighing Cabinets:
Standard weighing cabinets: These are general-purpose cabinets suitable for a wide range of applications.
Powder weighing cabinets: Designed specifically for handling powders, these cabinets often have specialized ventilation systems to prevent the spread of airborne particles.
Hazardous substance weighing cabinets: These cabinets are equipped with advanced safety features to protect operators from exposure to highly toxic or hazardous substances.
Factors to Consider When Choosing a Weighing Cabinet:
Safety requirements: Consider the specific hazards associated with the materials you will be handling and choose a cabinet that meets the appropriate safety standards.
Ventilation system: Evaluate the ventilation system to ensure it is adequate for your needs and complies with relevant regulations.
Size and capacity: Select a cabinet that is large enough to accommodate your weighing equipment and the materials you will be handling.
Ergonomics: Ensure that the cabinet's design is comfortable and ergonomic for the operator.
Additional features: Consider any additional features that may be beneficial, such as built-in lighting or power outlets.
By investing in a high-quality weighing cabinet, you can create a safe and controlled environment for your precision weighing operations, ensuring accurate results and protecting the health and safety of laboratory personnel.
